Senior Substation Physical Designer

Houston, Texas Permanent USD140,000 - USD150,000 per year Hybrid working View Job Description
The Senior Substation Physical Designer will lead the development of physical design packages for high-voltage substations, including equipment layouts, grounding, conduit, structural coordination, and construction drawings. This role partners with multidisciplinary engineering teams to deliver high-quality, constructible designs for utility and EPC projects ranging from 12kV to 500kV+.
  • Design high-voltage 12kV-500kV+ substation projects.
  • Work with a collaborative, experienced Power Delivery team.

About Our Client

Join a nationally recognized engineering and consulting firm delivering innovative solutions for utility infrastructure across North America. The team partners with electric utilities, renewable developers, and industrial clients to design and modernize transmission, distribution, and substation facilities that improve grid reliability and support the evolving energy industry.

Job Description

  • Develop physical design packages for AIS and GIS substations ranging from 12kV-500kV+.
  • Produce detailed engineering drawings including:
    • General arrangement plans
    • Plan and elevation views
    • Equipment layouts
    • Control building layouts
    • Conduit and trench plans
    • Grounding layouts
    • Lightning protection plans
    • Bus and rigid bus layouts
    • Structural steel and foundation drawings
  • Prepare material take-offs (MTOs) and Bills of Material (BOMs).
  • Coordinate physical design with Protection & Controls, Civil/Structural, Transmission Line, and Project Management teams.
  • Perform site walkdowns and incorporate field conditions into design packages.
  • Conduct QA/QC reviews to ensure compliance with client standards, NEC, NESC, IEEE, and utility specifications.
  • Support construction by responding to RFIs, reviewing submittals, and incorporating as-built revisions.
  • Lead design reviews with internal teams and clients.
  • Mentor junior designers and provide technical guidance on drafting standards and best practices.
